DIN17100 St52-3 Carbon and Low-alloy High-strength Steel Plate Chemical Composition and Mechanical Property
Mechanical Properties (MIN)
| Grade | Thickness (TH) (mm) | Yield Strength (N/mm²) | Tensile Strength (N/mm²) |
|---|---|---|---|
| ST52-3 | ≤16 | 355 | 510–680 |
| ST52-3 | >16 ≤40 | 345 | 490–630 |
| ST52-3 | >40 ≤63 | 335 | 490–630 |
| ST52-3 | >63 ≤80 | 325 | 490–630 |
| ST52-3 | >80 ≤100 | 315 | 490–630 |
| ST52-3 | >100 | — | — |
DIN17100 St52-3 Carbon and Low-alloy High-strength Steel Plate Application
DIN17100 St52-3 Steel Plates are used in Construction of Bridges, Highway Construction and Other Engineering construction
DIN17100 St52-3 Carbon and Low-alloy High-strength Steel Plate Other Name
DIN17100 St52-3 Carbon Structural Steel Plate, DIN17100 St52-3 High Strength Structural Steel Plate, DIN17100 St52-3 Carbon Steel plate, DIN17100 St52-3 Structural Steel Plate.
Additional Condition
UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.
